Overview
The Product provides customer with the most cost-effective solution for transmission of 1 channel uncompressed digital video, 1 reversed stereo audio and 1 reversed RS232/RS422/RS485 data over one single fiber cable. It is an easy installation and adjustment free device while providing high quality, real-time video. The product may also be maintained by our future product, FHC-6000M, a Network Management System.
Applications for this product include CCTV, video surveillance, homeland security, ITS and etc.

Features
Transport 1 channel digitized, high quality, uncompressed video
6.5MHz video bandwidth, Compatible with NTSC, PAL and SECAM
Provide 1 reversed stereo audio and 1 reversed data transmission over same optical fiber
Easy installation and adjustment free
Transmission range up to 120KM depending on model
RS232, RS422/RS485 compatible data interfaces
Stand alone operation or mount in Model FHC-6000-4U- chassis

Specifications
Power:
220VAC/50Hz, standalone device
1A@5VDC for rack card
Indicators:
Power, Link Status, Video Signal
Audio status, Data traffic
Video:
Format: PAL/NTSC/SECAM
Video Signal: 1Vp-p, 75Ω
Digitization: 8bits
Bandwidth 6.5MHz
DG <1%
DP <0.5o
SNR >60dB(weighted)
Connectors: 1 BNCs
Physical Dimensions:
175*25.3*222(mm) Card
158*36*214(mm) Standalone
Audio
Channel: 1 stereo audio
Audio Input: unbalanced, 600Ohms
Digitization: 16bit@48k
Frequency: 10Hz to 20KHz
SNR: >70dB
Connector: RCA
Data:
Channel: 1, Reversed
Data Rate: 0~~23.04Kbps/channel
Selectable RS-232/RS-422/RS-485
Connector: RJ45
Environment:
Operating: 0oC~+70 oC
Storage: -40oC~+85 oC
Humidity: 0-95% Non-Condensing


Note: SC connectors standard, consult factory for other connectors.
Add -M at the end of model number for rack card product
